DIMENSIONS:

Length - 12m
Length rear flap open - 13m
Width closed - 2.5m
Width expanded - 3.75m (expansion 1m, steps 1.25m)
Height - 3.875m (plus antenna height)

POWER:

1 x 63Amp 3Phase

VISION:

12 HD / Superlow, Smpte Fibre and Triax camera positions 8 Radio Camera Channels
Imagine IP3 146 x 144 3G/HD/SD hybrid router
Imagine 3G glue
Evertz 3G glue
48 monitor VIP production stack completely recon gurable Sony MVS8000AFS 3 ME DVE Switcher (with lance controller) 3 Main Transmission Paths & 22 external embedding outputs Valid Sync Generator
Complimentary Wifi

COMMS:

RTS ADAM 96 port matrix
2 channels of RTS 2 wire channels 2 TAIT talkback radio channels
2 Systembase dual ISDN Codec’s 8 external 4 wire channels
12 omnio external channels Telephone IFB, etc

SOUND:

Calrec Artemis Light
48 Line, 32 AES, 128 DANTE, 6 Madi I/O
48 Fader Surface
2 x Hydra remote stage boxes with 24 mic inputs and 8 line outputs each
Imagine IP3 Madi interface
Full multi mix 5.1 with Dolby E
Joco recorder with madi
SpotOn Audio 5.1 playback system UPM-1 Stereo to 5.1 upmix
OLED plus 12 monitor VIP displays

VT/EVS:

3 EVS XT3’s, 2 8ch, 1 12ch, X-File, IPDirector etc.
4 twin VTRS (HDCAM, XDCAM, Digital Betacam, etc.) FCP/AVID Edit
72 monitor VIP VT stack completely recon gurable Multi DVD and USB recording facilities

GRAPHICS:

2 Graphic machines Fill, Key, Pvw
